Airtac CPV10S Integrated Manifold Valve CPV10SJ03B12F
$207.01
Regular price
$214.51
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10SJ03B12F
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Modular integration of solenoid valves with unified inlet/exhaust ports and power supply (25-pin D-Sub connector), optimizing spatial efficiency while minimizing additional accessory requirements.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
Installation protocol:
Use M3 mounting screws with 0.4Nm torque limit. Maintain 20mm clearance
below valve for heat dissipation. Lubricate O-rings with PAG grease
during assembly. Perform 50% duty cycle max at 3Hz switching frequency.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B12F Technical Details
- Model: CPV10SJ03B12F
- Type: 3-position, 5-way integrated solenoid valve (Center closed)
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Voltage variants: DC24V (±10%), DC12V (customizable)
- Coil power: 1.6W (standard), 0.9W (low-power version available)
- Flow capacity: 650 l/min (Cv=1.2 at 0.5 MPa)
- Response time: ≤15ms (exhaust to actuation)
- Weight: 385g ±5g (including manifold base)
- Dimensions: 50mm(W) × 38mm(H) × 130mm(L)
- Seal material: Heat-resistant HNBR (-10℃ to 120℃)
- Protection class: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 5599-1 standard
- Mounting style: Sub-base compatible for multi-valve stacking
Modular pneumatic valve with integrated silencer and speed controller, featuring anti-vibration terminals and LED status indicator. The hardened aluminum alloy body withstands 10 million cycles minimum. Requires ISO 8573-1 Class 3 lubricated air (40μm filtration).
Industrial Applications:
- Multi-axis pneumatic actuator synchronization
- Bottle capping machine sequence control
- Textile machinery tension regulation systems
- Automated food processing line diverters
- Medical device pneumatic circuit isolation
Installation protocol:
Use M3 mounting screws with 0.4Nm torque limit. Maintain 20mm clearance
below valve for heat dissipation. Lubricate O-rings with PAG grease
during assembly. Perform 50% duty cycle max at 3Hz switching frequency.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B12F |
