Airtac CPV10S Integrated Manifold Valve CPV10SJ03B18F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve - CPV10SJ03B18F Technical Details
- Model: CPV10SJ03B18F
- Type: 5-port 3-position closed center (Integrated manifold valve)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Voltage options: DC24V (±10%) with DIN43650 connector
- Weight: 320g ±5% (including manifold base)
- Dimensions: 52mm(W) × 22mm(H) × 110mm(L)
- Flow rate: 750 L/min (ANR) at 0.5 MPa
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 60℃ (with anti-freeze measures below 0℃)
- Power consumption: 1.6W (Standard coil)/0.8W (Power-saving coil optional)
- Response time: ≤15ms (Exhaust to operation)
- Protection rating: IP67 (Dustproof and waterproof)
- Port thread depth: 12mm (Maximum engagement depth)
Modular pneumatic valve featuring multi-functional integration with built-in silencer and quick-connect terminals. The stacked design allows direct manifold mounting with other CPV series valves. Special shock-absorbing structure reduces vibration noise by 15dB compared to standard models. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Multi-axis robotic end effector control
- Pharmaceutical blister packaging machines
- Lithium battery formation equipment
- Semiconductor wafer handling systems
- Automotive tire assembly lines
Maintenance protocol:
Perform air bleeding after installation using the manual override button.
Replace desiccant cartridges every 2,000 operating hours in high-humidity environments.
Avoid parallel mounting with high-frequency inverters (min 50cm separation).
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B18F |
