Airtac CPV10S Integrated Manifold Valve CPV10SJ03B20F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B20F Technical Details
- Model: CPV10SJ03B20F
- Type: 5-port 3-position integrated solenoid valve (Mid-position closed)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including manifold base)
- Dimensions: 58mm(W) × 34mm(H) × 96mm(L)
- Seal material: HNBR rubber (FDA compliant option available)
- Temperature range: -10℃ to 80℃ (with anti-freeze kit: -20℃)
- Flow rate: 850 l/min (ANR) at 0.5 MPa
- Response time: ≤15ms (exhaust to actuation)
- Protection rating: IP67 (dust/water resistant)
- Port alignment: ISO 5599-1 standard
Modular pneumatic control unit combining solenoid valves and manifold, featuring dual-pressure operation capability. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Integrated surge suppression protects coils from voltage spikes. Requires 5μm filtered air with oil mist (ISO 8573-1 Class 3.4.2).
- Multi-axis pneumatic actuator synchronization
- Bottle capping machine pressure sequencing
- CNC tool changer mechanisms
- Automotive assembly line clamping systems
- Cleanroom-compatible medical device automation
Installation guidelines:
Mount on ISO standard manifold using M5 mounting screws (torque ≤1.2Nm).
Maintain ambient temperature below 60℃ with 15mm clearance for heat dissipation.
Use shock absorbers in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B20F |
