Airtac CPV10S Integrated Manifold Valve CPV10SJ03B24F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B24F Technical Specifications
- Model: CPV10SJ03B24F
- Type: 3-position 5-way solenoid valve (center closed)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage: DC24V ±10% (coil class F insulation)
- Power consumption: 2.5W (standard), 0.5W (power-saving mode)
- Response time: ≤15ms (exhaust to actuation)
- Weight: 520g ±5% (including manifold base)
- Dimensions: 124mm(L) × 50mm(W) × 83mm(H)
- Port thread depth: 12mm (maximum engagement)
- Seal material: HNBR (hydrogenated nitrile) with PTFE wear rings
- Temperature range: -10℃ to 60℃ (with anti-freeze measures below 0℃)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Manual override: Built-in mechanical operator with lock function
- Cycle life: ≥10 million operations (at rated conditions)
Modular pneumatic valve featuring ISO 15407-2 compliance with integrated silencer and surge suppression. The dual-coil latching design enables energy-efficient operation while maintaining position during power loss. Optimized flow paths achieve Cv=0.45 for medium-speed actuators. Compatible with vacuum applications when paired with EPDM seals (optional).
- Multi-axis pneumatic gripper coordination in assembly robots
- Indexing table position control with intermediate stops
- Plastic injection molding machine ejector systems
- Textile machinery tension control with mid-position damping
- Battery production line vacuum handling systems
Installation guidelines:
Use M5 mounting screws with 0.5Nm torque limit. Maintain 20mm clearance
below manifold for tubing access. Apply thread sealant only on male ports -
avoid contamination of pilot air passages. Perform 50 cycle burn-in before
critical operations.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B24F |
