Airtac CPV10S Integrated Manifold Valve CPV10SJ03B4F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B4F Technical Specifications
- Model: CPV10SJ03B4F
- Valve type: 3-position, 5-way (Integrated manifold base + solenoid coils)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 750 L/min (ANR)
- Response time: ≤15ms (at rated voltage)
- Weight: 1.25 kg (including manifold base)
- Dimensions: 100mm(L) × 42mm(W) × 76mm(H)
- Seal materials: HNBR/Nitrile compound (standard), optional FKM for high temp
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Protection class: IP67 (coils), IP40 (manifold)
- Port alignment: ISO 5599-1 standard
- Mounting torque: 1.5–2.0 N·m (for manifold screws)
High-density integrated valve system combining manifold and solenoid valves, featuring optimized flow paths for reduced pressure drop. The modular design allows cascade connection for multi-station control. Electro-pneumatic interface includes LED status indicators and manual overrides. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Multi-axis pneumatic actuator synchronization in assembly robots
- Plastic injection molding machine clamp controls
- Semiconductor wafer handling vacuum/pressure systems
- Beverage filling line multi-circuit distribution
- Textile machinery air-jet loom nozzle arrays
Maintenance protocol:
Perform lubrication every 2,000 operating hours using ISO VG32 turbine oil.
Avoid parallel installation spacing <50mm between manifolds. Ground terminal
resistance must be maintained below 100Ω for EMC compliance.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B4F |
