Airtac CPV10S Integrated Manifold Valve CPV10SJ03F18F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F18F Technical Specifications
- Model: CPV10SJ03F18F (Modular Base + Solenoid Coil)
- Valve type: 5/3-way closed center, double solenoid
- Port configuration: 10 ports (P1/P2/A1/A2/B1/B2/R1/R2/S1/S2)
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Max flow rate: 750 L/min (ANR) at 0.5 MPa
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Effective sectional area: 25mm² (Cv=1.3)
- Weight: 340g ±5% (valve body only), 480g ±5% (with coils)
- Dimensions: 82mm(L) × 38mm(W) × 104mm(H)
- Protection grade: IP67 (coils), IP40 (valve body)
- Electrical connection: DIN43650 Form A (with LED indicator)
High-density modular valve with integrated manifold design, featuring dual redundant exhaust paths and zero leakage spool design. The CPV10S series utilizes a unique "PowerCore" solenoid system achieving 30% faster response than standard valves. Includes manual override and position sensing ready design. Requires ISO 8573-1 Class 3 compressed air (max 50mg/m³ oil content).
- Multi-axis pneumatic manipulator control systems
- Bottle blowing machine clamp sequencing
- Lithium battery formation equipment pressure regulation
- Automated textile machinery tension control
- Semiconductor wafer handling vacuum/pressure switching
Installation protocol:
Mount horizontally with manifold alignment tolerance <0.1mm. Use M5x0.8 mounting screws torqued to 0.8N·m.
Maintain 15mm clearance below valve for condensate drainage. Perform weekly lubrication via AU-06S oil mist feeder.
Critical note:
Not compatible with phosphate ester fluids. Maximum 100,000 cycles/day at full load.
Requires surge protection for DC coils in high-vibration environments.
