Airtac CPV10S Integrated Manifold Valve CPV10SJ03F24F
$388.47
Regular price
$395.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10SJ03F24F
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Modular integration of solenoid valves with unified inlet/exhaust ports and power supply (25-pin D-Sub connector), optimizing spatial efficiency while minimizing additional accessory requirements.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
Installation note:
Requires 10-15Nm torque for manifold mounting. Use M3x0.5 screws with anti-vibration washers.
Maintain ≥20mm clearance below valve for cable management. Pre-flush air lines at 0.3MPa before commissioning.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F24F Specifications
- Model: CPV10SJ03F24F
- Type: 5-port 3-position integrated solenoid valve (Center closed)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage: DC24V ±10% (F24F suffix)
- Weight: 280g ±5g
- Dimensions: 52mm(L) × 38mm(W) × 78mm(H)
- Seal material: Heat-resistant NBR (up to 80℃)
- Temperature range: -5℃ to 80℃ (with intermittent 100℃ tolerance)
- Power consumption: 1.6W (standard coil)
- Response time: ≤15ms (at 0.5MPa)
- Flow rate: 750 L/min (ANR)
- Protection rating: IP67 (dust/water resistant)
- Port alignment: ISO 5599-1 standard
High-density integrated valve combining manifold and solenoid valves, featuring dual-coil latching design for energy efficiency. The aluminum alloy body with hard anodizing ensures corrosion resistance in humid environments. Includes manual override and surge protection circuitry.
Typical Applications:
- Multi-axis pneumatic robotic arms
- Beverage filling line control systems
- Lithium battery production equipment
- Cleanroom automation (ISO Class 5-8)
- High-cycle packaging machinery (≥1M cycles/year)
Installation note:
Requires 10-15Nm torque for manifold mounting. Use M3x0.5 screws with anti-vibration washers.
Maintain ≥20mm clearance below valve for cable management. Pre-flush air lines at 0.3MPa before commissioning.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F24F |
