Airtac CPV10S Integrated Manifold Valve CPV10SJ04B14F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ04B14F Technical Details
- Model: CPV10SJ04B14F
- Type: 4-position 5-way pilot-operated solenoid valve
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 54mm(W) × 54mm(H) × 134mm(L)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 60℃ (with anti-freeze measures)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (exhaust to actuation)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
- Max flow rate: 750 L/min (ANR)
Modular manifold valve with integrated silencer and speed controller, featuring dual-pressure operation capability. The hardened aluminum alloy body with chromed piston ensures 2 million+ cycle durability. Includes manual override and position indicator. Requires ISO 8573-1 class 3 lubricated air (40μm filtration).
- Multi-axis pneumatic actuator synchronization
- Automated assembly line clamping systems
- Plastic injection molding machine controls
- Textile machinery air circuit management
- Semiconductor wafer handling robots
Installation protocol:
Mount on ISO 15407-1 compliant manifold base. Maintain ambient humidity below 85% RH.
For horizontal mounting, install exhaust ports downward. Lubricate quarterly with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | CPV10SJ04B14F |
