Airtac CPV10S Integrated Manifold Valve CPV10SJ04B22F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ04B22F Technical Specifications
- Model: CPV10SJ04B22F
- Type: 4-port 5-way integrated solenoid valve (monostable)
- Port configuration: P, A, B, R1, R2 (1/8" NPT standard)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (Cv=1.2) at 0.5 MPa
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 520g ±5% (with all solenoids installed)
- Dimensions: 98mm(L) × 34mm(W) × 72mm(H)
- Seal materials: Main seals NBR, optional FKM available
- Ambient temperature: -5℃ to 60℃ (no freeze condensation)
- Coil insulation class: Class F (155℃)
- Protection rating: IP67 (connector installed)
- Manual override: Built-in push-button (per valve unit)
High-density modular valve combining four independent 5-way valves in a single manifold block. Features anti-vibration structure with stainless steel plunger guides and gold-plated connectors. Optimized for multi-cylinder sequencing with parallel wiring capability and LED status indicators. Requires 5μm filtered lubricated air (ISO 8573-1:2010 class 4.4.3).
- Multi-axis pneumatic robotics (pick-and-place systems)
- Bottle cap sorting & capping machine clusters
- PCB handling equipment with vacuum/pressure switching
- Automated textile machinery with multi-position actuators
- Pharmaceutical blister packaging lines
Installation protocol:
Mount on flat surface with M4 screws (torque ≤0.8N·m). Maintain ≥15mm
clearance below manifold for tubing. Use shielded cables for EMI-sensitive
environments. Perform weekly manual cycling in high-humidity applications.
| Property | Property Value |
|---|---|
| sku | CPV10SJ04B22F |
