Airtac CPV15M Manifold Base CPV15M19F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M19F Cylinder Mounting Bracket Detailed Specifications
- Model: CPV15M19F
- Compatible Series: CPV15M standard cylinders
- Material: Aluminum alloy ADC12 (anodized finish)
- Mounting Type: Dual-rail side mount with M5 threaded holes
- Bore Size Compatibility: Ø15mm cylinders
- Mounting Hole Pattern: 19mm center-to-center spacing
- Surface Hardness: HV 80-100
- Operating Temperature: -20℃ to 100℃
- Max Lateral Load Capacity: 25N
- Weight: 98g ±2g
- Dimensions: 42mm(L) × 28mm(W) × 19.5mm(H)
- Corrosion Resistance: 96hr salt spray test compliant
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered mounting base for CPV series compact cylinders, featuring anti-rotation design with integrated alignment pins. The diamond-knurled surface ensures secure grip during installation while the through-hole design allows for optional secondary securing with M5 fasteners. Compatible with both horizontal and vertical mounting orientations.
- Modular pneumatic assembly systems
- Precision pick-and-place unit carriers
- Semiconductor handling equipment
- Medical device actuation mechanisms
- Automated test fixture positioning
Installation Best Practices:
Apply 0.3-0.5Nm torque limit on mounting screws. Use shim washers when
mounting on uneven surfaces. For vibration-heavy environments,
apply thread-locking compound to fasteners.
