Airtac CPV15M Manifold Base CPV15M7F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M7F Cylinder Mounting Bracket Specifications
- Model: CPV15M7F (Compatible with CPV15M series cylinders)
- Material: Aluminum alloy ADC12 with anodized surface treatment
- Mounting type: Foot-mounted with 2 fixing holes
- Hole spacing: 30mm ±0.2mm (center-to-center)
- Bolt size: M5×0.8 thread specification
- Surface hardness: HV 120±15 (anodized layer)
- Weight: 82g ±3g
- Dimensions: 40mm(L) × 28mm(W) × 15mm(H)
- Operating temperature: -20℃ to 80℃ (non-condensing)
- Corrosion resistance: 96hr salt spray test compliant
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
Precision-engineered mounting base for compact pneumatic cylinders, featuring anti-vibration design with reinforced rib structure. The diamond-knurled surface enhances grip during installation while maintaining dimensional stability under cyclic loading. Includes stainless steel insert nuts for repeated disassembly capability.
- Robotic end-effector positioning systems
- Semiconductor wafer handling equipment
- Conveyor sorting mechanisms
- Precision optical lens adjustment devices
- 3D printer extruder head assemblies
Installation note:
Apply 2.0-3.5N·m torque during fastening and use spring washers
for dynamic load applications. Ensure cylinder rod axis remains
perpendicular within ±2° tolerance.
| Property | Property Value |
|---|---|
| sku | CPV15M7F |
