Airtac CPV15M Manifold Base CPV15M9F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M9F Cylinder Mounting Bracket Specifications
- Model: CPV15M9F
- Compatibility: Designed for CPV15M series cylinders
- Material: Aluminum alloy (ADC12)
- Surface treatment: Anodized oxidation
- Mounting hole spacing: 30±0.2mm (horizontal) × 18±0.2mm (vertical)
- Fastener specification: M6×1.0 thread
- Load capacity: Max 150N static load
- Operating temperature: -20℃ to 80℃
- Weight: 215±5g
- Dimensions: 62mm(L) × 42mm(W) × 22mm(H)
- Mounting orientation: Universal (horizontal/vertical/ceiling)
- Vibration resistance: ≤15Hz (amplitude ≤1mm)
Robust mounting solution for CPV15M pneumatic cylinders, featuring precision-machined alignment grooves and reinforced stress points. The thermal-conductive design helps dissipate cylinder heat during continuous operation. Includes integrated cable management channels for sensor wiring.
- Robotic arm joint articulation systems
- Conveyor belt tensioning mechanisms
- Automated packaging machine pushers
- CNC machine tool clamping units
- Pharmaceutical filling station actuators
Installation note:
Apply 5-7Nm torque when tightening mounting bolts. Use shim washers
when installing on uneven surfaces (>0.3mm flatness deviation).
| Property | Property Value |
|---|---|
| sku | CPV15M9F |
