Airtac CPV15S Integrated Valve Manifold CPV15S12F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features modular design with flexible expandability, allowing arbitrary combination and extension of connected solenoid valves. Optional blanking plates included for configuration flexibility.
Category: Solenoid Valve Manifold Base , Brand: AirTAC , Series: CPV15S
AirTAC CPV15S12F Modular Valve Base Specifications
- Model: CPV15S12F (CPV15S Series)
- Type: Modular aluminum manifold base for solenoid valve stacking
- Port configuration: 12 stations (12F) with 1/8" NPT ports
- Material: Aluminum alloy 6063-T5 with hard anodized surface
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max flow capacity: 850 L/min (Cv=1.2)
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Surface roughness: Ra ≤1.6μm (sealing areas)
- Mounting torque: 1.2–1.5 N·m for valve installation
- Weight: 520g ±3% (bare base without valves)
- Dimensions: 150mm(L) × 30mm(W) × 40mm(H)
- Port alignment: ISO 5599-1 standard pattern
- Compatibility: Works with CPV10/15/20 series valves
Precision-machined manifold base enabling multi-valve integration with centralized air distribution. Features cross-drilled internal passages for minimized pressure drop and staggered port layout for easy tubing access. Includes built-in mounting slots for DIN rail or direct panel attachment.
- Automated assembly line multi-actuator control
- Robotic end-effector pneumatic systems
- Beverage filling machine cluster valve arrangements
- Semiconductor handling equipment
- Multi-cylinder sequencing systems
Installation note:
Use M5×12mm mounting screws (not included) with 0.6–0.8 N·m torque.
Apply sealant grease (AS-7306 recommended) to valve mating surfaces
before assembly. Maximum 16 valves can be stacked per base.
