Airtac DPC Compact Non-display Pressure Switch DPC-0103008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC Miniature Display-Free Pressure Switch DPC-0103008 Technical Details
- Model: DPC-0103008
- Type: Compact electromechanical pressure switch (non-display)
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Port size: G1/8 (BSPP thread) with 4.5mm push-in fitting
- Electrical rating: 250V AC/30V DC, 5A resistive load
- Contact configuration: SPDT (1NO+1NC)
- Hysteresis: ≤10% of set pressure value
- Repeat accuracy: ±2% F.S.
- Proof pressure: 1.5 MPa (217.5 PSI)
- Housing material: Glass-filled PA66 (UL94 V-0)
- Seal material: HNBR (Hydrogenated Nitrile)
- Protection class: IP67 (NEMA 6 equivalent)
- Temperature range: -20℃ to +80℃ (-4°F to +176°F)
- Weight: 98g ±2g (including terminals)
- Dimensions: 38mm(W) × 42mm(H) × 28mm(D)
- Terminal type: 6.3mm blade connector (supports 16-14 AWG)
- Response time: ≤2ms (mechanical contact operation)
- Certifications: CE, RoHS, REACH compliant
Ultra-compact pressure monitoring solution with industrial-grade durability, featuring a fully sealed aluminum alloy sensing element. The snap-action mechanism provides crisp switching characteristics unaffected by vibration. Includes manual setpoint adjustment via recessed potentiometer (requires 2mm hex tool). Designed for direct integration into pneumatic manifolds with optional DIN rail mounting kit (sold separately).
- Compressed air system pressure monitoring
- Hydraulic pump overload protection
- Medical oxygen concentrator safety cutoff
- Packaging machine clamp force regulation
- EV battery cooling system pressure feedback
- Industrial coffee machine boiler controls
Installation guidelines:
Mount in vibration-free location with arrow marking aligned to flow direction.
Use thread sealant on port connections (PTFE tape not recommended).
Allow 5-minute stabilization period after power cycling for accurate calibration.
| Property | Property Value |
|---|---|
| sku | DPC-0103008 |
| Pneumatic Connector | PT1/4 |
