Airtac DPC Compact Non-display Pressure Switch DPC-01030D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-01030D4 Compact Pressure Switch Technical Specifications
- Model: DPC-01030D4
- Type: Non-display electromechanical pressure switch
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Electrical rating: DC24V ±10% / AC220V ±10% (50/60Hz)
- Current capacity: 3A (resistive load)
- Output type: SPDT contact (1NO+1NC)
- Port size: PT1/8 (G1/8 optional)
- Housing material: Glass-fiber reinforced PBT
- Seal material: HNBR (hydrogenated nitrile)
- Temperature range: -20℃ to 85℃ (operating fluid)
- Protection class: IP67 (dust/water resistant)
- Mechanical life: ≥1,000,000 cycles
- Weight: 98g ±2g
- Dimensions: 32mm(W) × 32mm(D) × 43.5mm(H)
Ultra-compact pressure monitoring solution with robust stainless steel sensing element. Features zero pressure loss design and vibration-resistant construction. Calibrated for ±1.5% F.S. accuracy with manual hysteresis adjustment via hex key. Integrated cable gland supports Ø4–7mm wiring.
- Hydraulic pump overload protection systems
- Compressed air line pressure monitoring
- Medical oxygen concentrator safety cutoff
- Beverage dispensing machine pressure control
- EV battery cooling system diagnostics
Installation guidelines:
Mount in vibration-free locations using M4 screws (max torque 1.2N·m).
Maintain minimum 50mm clearance from electromagnetic sources.
Use dry, oil-free compressed air (ISO 8573-1:2010 Class 2.4.2 recommended).
| Property | Property Value |
|---|---|
| sku | DPC-01030D4 |
| Pneumatic Connector | <4mm> |
