Airtac DPC Compact Non-display Pressure Switch DPC-1002008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-1002008 Compact Pressure Switch Specifications
- Model: DPC-1002008
- Type: Non-display miniature pressure switch
- Pressure range: 0.1-1.0 MPa (14.5-145 PSI)
- Electrical rating: 1A @ 250V AC/DC (SPDT contact)
- Port size: PT1/8 (NPT1/8 optional)
- Pressure connection: G1/8 female thread
- Hysteresis: ≤10% of set pressure
- Repeat accuracy: ±2% F.S.
- Proof pressure: 1.5 MPa
- Operating temperature: -5℃ to 60℃
- Housing material: Glass-filled PBT
- Seal material: NBR (nitrile rubber)
- Protection rating: IP40
- Weight: 98g ±2g
- Dimensions: 34mm(W) × 22mm(D) × 45mm(H)
Ultra-compact electromechanical pressure switch with precision microswitch mechanism. Features anti-vibration design with ±3% FS setting accuracy and manual pressure adjustment screw (2mm hex key required). Built-in snubber prevents pressure spikes. Compatible with air/N2 and hydraulic fluids (NBR compatibility dependent).
- Compressed air system pressure monitoring
- Hydraulic pump overload protection
- Medical oxygen concentrators
- Industrial robot end-effector controls
- Beverage dispensing machine pressure cutoff
- HVAC refrigerant pressure safety switches
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (max torque 1.2N·m).
Allow 15mm clearance for adjustment access. Use thread sealant on pressure port
(PTFE tape not recommended). Perform initial calibration at 25℃ ambient temperature.
| Property | Property Value |
|---|---|
| sku | DPC-1002008 |
| Pneumatic Connector | PT1/4 |
