Airtac DPC Compact Non-display Pressure Switch DPC-10020D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-10020D4 Compact Pressure Switch Technical Details
- Model: DPC-10020D4
- Type: Digital pressure switch (non-display type)
- Pressure range: -0.1~1.0 MPa (vacuum to positive pressure)
- Set pressure adjustment: Rotary dial with ±2% FS accuracy
- Electrical rating: 12-24VDC ±10%
- Output type: PNP/NPN selectable, 100mA max
- Port size: G1/8 (NPT1/8 optional)
- Housing material: Stainless steel (SUS304) body with PA66 housing
- Seal material: FKM fluorocarbon rubber
- Temperature range: -20℃ to 85℃ (operating), -30℃ to 100℃ (storage)
- Response time: ≤2ms
- Protection rating: IP67 (connector installed), IP65 (with cable)
- Vibration resistance: 10~2000Hz, 20G acceleration
- Weight: 185g ±5g
- Dimensions: 60mm(L) × 36mm(W) × 38mm(H)
Ultra-compact digital pressure switch featuring military-grade shock resistance and chemical-resistant sealing. The dual-range hysteresis adjustment (via internal DIP switches) enables precise deadband control for critical pressure monitoring. Includes reverse polarity protection and short-circuit prevention circuitry.
- Mobile hydraulic systems in construction machinery
- Vacuum pick-and-place automation systems
- Medical gas pressure monitoring
- EV battery cooling system pressure control
- Semiconductor manufacturing equipment
Installation guidelines:
Mount using M4 screws with vibration-proof washers. Maintain minimum 10mm clearance from high-frequency EMI sources.
For liquid applications, orient port downward to prevent air bubble accumulation. Perform zero-point calibration after 500hrs of initial operation.
| Property | Property Value |
|---|---|
| sku | DPC-10020D4 |
| Pneumatic Connector | <4mm> |
