Airtac DPC Compact Non-display Pressure Switch DPC-1003008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-1003008 Compact Pressure Switch Technical Details
- Model: DPC-1003008 (DPC Series)
- Type: Non-display electromechanical pressure switch
- Pressure range: 0.05–1.6 MPa (7–232 psi)
- Electrical rating: SPDT contact 5A @ 250VAC
- Port connection: 1/8" PT (G1/8 optional)
- Housing material: Glass-filled PBT (UL94 V-0)
- Seal material: HNBR (Hydrogenated Nitrile)
- Accuracy: ±1.5% full scale (FS)
- Hysteresis: ≤2% FS
- Proof pressure: 3.2 MPa (464 psi)
- Electrical connection: 3-pin M8 connector (IP67 rated)
- Operating temp: -20℃ to 85℃ (-4°F to 185°F)
- Protection class: IP65 (NEMA 4X equivalent)
- Vibration resistance: 10–55Hz @ 1.5mm amplitude
- Weight: 85g ±2g (including connector)
- Dimensions: 25mm(W) × 25mm(D) × 40mm(H)
Ultra-compact pressure monitoring solution with industrial-grade durability. Features brass pressure port with anti-vibration thread design and gold-plated contacts for reliable switching. The membrane isolation structure prevents media contamination, suitable for air/neutral gases. Includes adjustable setpoint via internal trimmer (requires tool calibration).
- Mobile hydraulic power units pressure safeguarding
- Inline pressure monitoring in pneumatic conveyor systems
- Overpressure cutoff for dental chair pneumatic circuits
- Compressor auto-stop systems in refrigeration units
- Battery-powered IoT environmental monitoring stations
Installation protocol:
Mount in vibration-free locations using M3 screws (max torque 0.6Nm).
For liquid applications, orient port downward. Allow 30 sec stabilization
after power-on before calibration. Replace O-rings annually in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | DPC-1003008 |
| Pneumatic Connector | PT1/4 |
