Airtac DPC Compact Non-display Pressure Switch DPC-1005008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC Miniature Display-Free Pressure Switch DPC-1005008 Specifications
- Model: DPC-1005008
- Type: Compact electromechanical pressure switch
- Pressure range: -0.1~1.6 MPa (adjustable)
- Port size: Rc1/8 (G1/8 optional)
- Electrical rating: 250V AC / 5A (resistive load), 250V AC / 3A (inductive load)
- Contact configuration: SPDT (1C/O)
- Hysteresis: ≤10% of set value
- Repeat accuracy: ±2% F.S.
- Proof pressure: 2.4 MPa
- Ambient temperature: -5℃ to 70℃
- Protection rating: IP54
- Housing material: Glass-filled nylon (PA66+30%GF)
- Seal material: Fluororubber (FKM)
- Weight: 85g ±2g
- Dimensions: 54mm(L) × 32mm(W) × 38mm(H)
Ultra-compact pressure monitoring solution with ruggedized construction, featuring dual-scale pressure indication (MPa/psi) through color-coded adjustment dial. The brass-free fluid path design prevents corrosion in humid environments. Integrated microswitch provides ≤5ms response time for critical pressure threshold detection.
- Compressed air system pressure safeguarding
- HVAC refrigerant line monitoring
- Hydraulic pump overload protection
- Portable medical oxygen concentrators
- Beverage dispensing machine pressure control
Installation guidelines:
Mount in vibration-free locations using M4 screws (max torque 1.2N·m).
For gas applications, orient port downward to prevent liquid ingress.
Allow 15mm clearance around adjustment screw for calibration access.
| Property | Property Value |
|---|---|
| sku | DPC-1005008 |
| Pneumatic Connector | PT1/4 |
