Airtac DPC Compact Non-display Pressure Switch DPCN-0102008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-0102008 Compact Pressure Switch Specifications
- Model: DPCN-0102008
- Type: Non-display miniature pressure switch
- Pressure range: -0.1~1.0 MPa (switch point adjustable)
- Electrical rating: 250V AC / 5A (resistive load), 250V AC / 1A (inductive load)
- Port size: Rc1/8 (G1/8 optional)
- Housing material: Glass-filled PBT (UL94 V-0 rated)
- Seal material: HNBR (hydrogenated nitrile)
- Operating temperature: -5℃ to 80℃ (no freezing)
- Protection class: IP65 (terminal cover closed)
- Contact configuration: SPDT (1NO+1NC)
- Hysteresis: ≤10% of set pressure value
- Repeat accuracy: ±1% F.S.
- Weight: 85g ±2g
- Dimensions: 48mm(L) × 28mm(W) × 39mm(H)
- Certification: CE, RoHS compliant
Ultra-compact electromechanical pressure switch with precision brass sensing element, featuring vibration-resistant construction and manual setpoint adjustment via hex key. The encapsulated microswitch ensures reliable operation in high-humidity environments. Includes dual-color status LED (red/green) for visual feedback without display.
- Compressed air system pressure monitoring
- HVAC refrigerant circuit protection
- Mobile hydraulic equipment safety cutoff
- Water treatment pump control systems
- 3D printer pneumatic bed leveling systems
Installation guidelines:
Mount in vibration-free location using M4 screws (max torque 1.2N·m).
For liquid applications, orient port downward to prevent pooling.
Allow 2-minute stabilization after pressure adjustment.
| Property | Property Value |
|---|---|
| sku | DPCN-0102008 |
| Pneumatic Connector | PT1/4 |
