Airtac DPC Compact Non-display Pressure Switch DPCN-01020D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-01020D6 Compact Pressure Switch Technical Details
- Model: DPCN-01020D6
- Type: Non-display miniature pressure switch
- Pressure range: 0.02–1.0 MPa (adjustable)
- Setting accuracy: ±0.01 MPa
- Port size: Rc1/8 (G1/8 optional)
- Electrical rating: 5A 250V AC / 5A 30V DC
- Contact type: SPDT (1NO+1NC)
- Housing material: Glass-filled nylon (UL94 V-0)
- Seal material: Fluororubber (FKM)
- Proof pressure: 1.5 MPa
- Operating temperature: -5℃ to 80℃
- Protection rating: IP54 (terminal cover closed)
- Vibration resistance: 10–55Hz, 1.5mm double amplitude
- Shock resistance: 100m/s² (3 axes)
- Weight: 85g ±2g
- Dimensions: 48mm(L) × 34mm(W) × 38mm(H)
- Certification: CE, RoHS compliant
Ultra-compact electromechanical pressure switch featuring tool-free calibration via built-in adjustment screw. The brass pressure port with FKM seals ensures chemical resistance in harsh environments. Integrated anti-vibration structure maintains stable operation in mobile applications.
- Compact pneumatic control cabinets
- Medical oxygen concentrators
- Beverage dispensing systems
- HVAC refrigerant pressure monitoring
- Robotic gripper pressure feedback
- Electric air compressor safety cutoff
Installation guidelines:
Mount in vibration-free locations using M4 screws (max torque 1.2N·m).
For liquid applications, orient port downward to prevent pooling.
Allow 30s stabilization after pressure adjustment.
| Property | Property Value |
|---|---|
| sku | DPCN-01020D6 |
| Pneumatic Connector | <6mm> |
