Airtac DPC Compact Non-display Pressure Switch DPCN-0103008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-0103008 Compact Pressure Switch Technical Details
- Model: DPCN-0103008
- Type: Non-display miniature pressure switch
- Pressure setting range: 0.1-1.0 MPa (14.5-145 PSI)
- Proof pressure: 1.5 MPa (217.5 PSI)
- Switch type: SPDT (Single Pole Double Throw)
- Contact capacity: 250V AC 5A / 24V DC 5A (resistive load)
- Port size: Rc1/8 (G1/8) female thread
- Pressure element: Stainless steel diaphragm
- Housing material: Nickel-plated brass
- Seal material: NBR (Nitrile rubber)
- Electrical connection: 3-pin M8 connector (IP67 rated)
- Hysteresis: ≤10% of set pressure
- Repeat accuracy: ±2% F.S.
- Temperature range: -20℃ to 80℃ (operation) / -30℃ to 100℃ (storage)
- Protection rating: IP65 (front face)/IP40 (terminal side)
- Weight: 215g ±5g
- Dimensions: 48mm(W) × 48mm(H) × 34.5mm(D)
Ultra-compact electromechanical pressure switch featuring stainless steel sensing element with anti-vibration design. Provides precise pressure monitoring through adjustable setpoint screw (accessible via 3mm hex key). The shock-resistant structure maintains stable operation under 10G vibration (10-2000Hz). Includes built-in silicone damping ring for pulsation reduction.
- Mobile hydraulic power units pressure safeguard
- CNC machine tool lubrication system monitoring
- Food processing pneumatic line pressure control
- Electric vehicle battery cooling system protection
- Robotic gripper force feedback systems
Installation guidelines:
Mount in vibration-free location using M4 screws (max torque 1.2N·m).
For liquid applications, orient port downward to prevent air entrapment.
Allow 15mm clearance around adjustment screw for maintenance access.
| Property | Property Value |
|---|---|
| sku | DPCN-0103008 |
| Pneumatic Connector | PT1/4 |
