Airtac DPC Compact Non-display Pressure Switch DPCN-0105008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-0105008 Compact Pressure Switch Specifications
- Model: DPCN-0105008
- Type: Non-display miniature pressure switch
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Port size: 1/8" NPT (BSPP available on request)
- Electrical rating: 5A @ 250V AC, 5A @ 30V DC
- Contact configuration: SPDT (Single Pole Double Throw)
- Hysteresis: ≤10% of set pressure value
- Repeat accuracy: ±1% F.S.
- Proof pressure: 1.5 MPa (217.5 PSI)
- Temperature range: -20℃ to 80℃ (operating fluid)
- Housing material: Glass-filled nylon (UL94 V-0)
- Weight: 98g ±2g
- Dimensions: 34mm(W) × 34mm(H) × 42mm(D)
- Protection rating: IP50 (terminal box area)
- Response time: ≤2ms
- Electrical connection: 3-pin terminal (18-22 AWG)
Ultra-compact electromechanical pressure switch with industrial-grade durability, featuring a fully sealed stainless steel sensing element. The brass-free design prevents dezincification in humid environments. Includes vibration-resistant contacts rated for 1 million cycles at full load.
- Mobile hydraulic power units
- Compressed air leak detection systems
- 3D printer pneumatic extruder controls
- Refrigeration cycle pressure monitoring
- Robotic gripper force feedback systems
- Beverage dispensing machine pressure cutoff
Installation guidelines:
Mount in vibration-free locations using the M4 mounting holes.
Use thread sealant on male ports (DO NOT overtighten - max 15N·m).
Allow 2-3 pressure cycles for initial calibration stabilization.
Critical note:
Requires filtered air/oil mist (ISO 8573-1:2010 Class 4.4.2).
Never use silicone-based lubricants - incompatible with nylon housing.
| Property | Property Value |
|---|---|
| sku | DPCN-0105008 |
| Pneumatic Connector | PT1/4 |
