Airtac DPC Compact Non-display Pressure Switch DPCN-10020D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-10020D6 Compact Pressure Switch Specifications
- Model: DPCN-10020D6
- Type: Non-display electromechanical pressure switch
- Pressure range: -0.1~1.0 MPa (customizable up to 10 MPa)
- Setting method: Hex key rotary adjustment
- Electrical contact: SPDT (1C) micro switch
- Contact capacity: 15A 250VAC / 0.5A 125VDC (resistive)
- Voltage rating: ≤250VAC/DC
- Protection rating: IP65 (NEMA 4X equivalent)
- Port size: PT1/8 (NPT1/8 optional)
- Housing material: Stainless steel SS304
- Seal material: Fluororubber (FKM)
- Temperature range: -20℃ to 80℃ (operation), -30℃ to 100℃ (storage)
- Proof pressure: 1.5x rated pressure
- Repeat accuracy: ±1% F.S.
- Response time: ≤2ms
- Mechanical life: 10 million cycles
- Weight: 85g ±3%
- Dimensions: 35mm(W) × 35mm(D) × 35mm(H) (excluding fittings)
Ultra-compact pressure monitoring solution with military-grade shock resistance (100G acceleration tolerance). Features dual-chamber diaphragm sensing technology for stable detection in pulsating systems. The all-metal construction enables use in high-humidity and chemical exposure environments. Includes anti-vibration locknut and orientation-independent mounting capability.
- Industrial automation safety interlocks
- Pneumatic press overload protection
- Medical gas cylinder pressure monitoring
- HVAC refrigerant pressure cutoff
- Packaging machine clamp force verification
- Robotic gripper pressure feedback systems
Installation guidelines:
Mount using 22mm open-end wrench on hex body. For liquid applications,
orient port downward to prevent pooling. Allow 5 pressure cycles
before calibration. Maximum torque 15N·m during plumbing connection.
| Property | Property Value |
|---|---|
| sku | DPCN-10020D6 |
| Pneumatic Connector | <6mm> |
