Airtac DS1F Electronic Sensor DS1F050
2. The device typically comprises four core components: temperature sensing probe, signal processing unit, digital display interface, and power supply system.
3. As the sensitive component, the temperature probe employs single or multiple high-precision fast-response thermistors, which critically determine both temperature measurement accuracy (typical tolerance ±0.5°C) and rapid response characteristics (≤200ms).
AirTAC DS1F050 Electronic Sensor Technical Details
- Model: DS1F050
- Type: Rectangular DC 3-wire inductive proximity sensor
- Detection distance: 5mm ±10% (adjustable)
- Supply voltage: 10-30V DC
- Output type: NPN/PNP NO/NC selectable (4-in-1 configurable)
- Current consumption: ≤15mA
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Sensing face: PBT resin
- Temperature range: -25℃ to +70℃
- Vibration resistance: 10-55Hz 1.5mm double amplitude
- Shock resistance: 1000m/s² (3-axes)
- Connection: 2m PVC cable (M8 connector optional)
- Weight: 150g ±5%
- Dimensions: 60mm(L) × 25mm(W) × 15mm(H)
High-precision industrial proximity sensor with temperature compensation circuitry, featuring dual-color LED status indication (red/green for power/detection). The anti-interference design incorporates surge protection and reverse polarity protection. Optimized for metal object detection in harsh environments with oil mist or dust.
- Position verification in automated conveyor systems
- End-of-stroke detection for pneumatic cylinders
- Liquid level monitoring in food packaging lines
- Safety interlocks in automotive assembly robots
- Tool presence verification in CNC machines
Installation guidelines:
Maintain 2× sensor diameter clearance from adjacent metal surfaces.
For optimal performance, align target perpendicular to sensing face
and perform teach-in calibration after installation. Avoid mounting
near high-frequency equipment without proper shielding.
| Property | Property Value |
|---|---|
| sku | DS1F050 |
