Airtac ESV-M Base ESV201MGB
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Series Base ESV201MGB Technical Specifications
- Model: ESV201MGB (ESV-M series modular base)
- Type: ISO 5599/1 standard interface manifold base
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage compatibility: Compatible with DC24V/AC220V solenoid coils
- Weight: 320±5g
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Material: Anodized aluminum alloy (black oxidation treatment)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 80℃
- Flow capacity: 850 l/min (ANR)
- Mounting: Horizontal manifold assembly
- Surface roughness: Ra ≤ 3.2μm
- Protection rating: IP67 (when assembled with compatible valves)
Modular valve base designed for multi-valve stacking configurations, featuring precision-machined air passages with leak-proof design. The hard anodized surface provides exceptional corrosion resistance in humid environments. Integrated T-slot design allows tool-free valve mounting and supports up to 20-valve bank assemblies without additional brackets.
- Centralized pneumatic control systems
- Multi-station industrial automation lines
- Food processing machinery (NSF compliant seals)
- Semiconductor manufacturing equipment
- Automotive assembly line actuators
Installation note:
Ensure manifold surfaces are clean and free from particles before assembly.
Use specified torque (1.5N·m) when connecting multiple bases.
Requires 5μm filtered air supply with oil mist lubrication (ISO VG32 recommended).
- ESV-M series valves (ESV201M-XX)
- AVM-04/06 series solenoid valves
- ISO 15407-1 standard valves
| Property | Property Value |
|---|---|
| sku | ESV201MGB |
| Port Size | PT1/4 |
