Description
ESV-M Base Features:
1. Sleek appearance with compact structural design;
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
Installation protocol:
Use M4×12 mounting screws (1.2-1.5N·m torque). Apply silicone-free grease to O-rings.
Maximum stack height: 16 modules. Requires 0.5m clearance above for maintenance access.
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base ESV202MGW Technical Specifications
- Model: ESV202MGW (ESV-M series)
- Type: Modular valve manifold base
- Port configuration: 2-position manifold base
- Port size: 1/8" NPT (G1/8 optional)
- Max operating pressure: 1.0 MPa
- Voltage compatibility: DC12V-24V / AC110V-220V (varies with solenoid)
- Weight: 320g ±5g
- Dimensions: 72mm(L) × 25mm(W) × 44mm(H)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Flow capacity: 450 NL/min (ANR)
- Surface finish: Anodized aluminum alloy
- Mounting pattern: ISO 15407-2 compliant
- Port pitch: 20mm (modular spacing)
- Protection rating: IP67 (when assembled with compatible valves)
Precision-engineered modular base with optimized flow channels for multi-valve configurations. Features dual-row O-ring sealing system for leak-free operation in high vibration environments. The staggered port design minimizes pressure drop across multiple connected valves.
Typical Applications:
- Multi-axis pneumatic control systems
- Automated assembly line manifolds
- Semiconductor wafer handling equipment
- Textile machinery pneumatic clusters
- Beverage filling machine valve banks
Installation protocol:
Use M4×12 mounting screws (1.2-1.5N·m torque). Apply silicone-free grease to O-rings.
Maximum stack height: 16 modules. Requires 0.5m clearance above for maintenance access.
Compatibility:
Interfaces with ESV-M series valves (ESV-M5/10/15). Not compatible with ESV-5/10 legacy series.
Use with filtered compressed air (5-50μm filter, dew point -20℃ below ambient).
| Property | Property Value |
|---|---|
| sku | ESV202MGW |
| Port Size | PT1/4 |
