Airtac ESV-M Base ESV301M
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base Manifold ESV301M Technical Specifications
- Model: ESV301M (ESV-M Series)
- Type: Modular valve base manifold for multiple valve assembly
- Port configuration: 3/2-way valve mounting base
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.1–1.0 MPa
- Max flow capacity: 750 L/min (ANR)
- Voltage compatibility: Supports all ESV-M series solenoid voltages (DC12V/24V, AC110V/220V)
- Weight: 385g ±5g
- Dimensions: 52mm(W) × 39mm(H) × 86mm(L)
- Mounting pitch: 21mm between valve stations
- Seal material: HNBR (Hydrogenated Nitrile) with stainless steel reinforcement
- Temperature resistance: -20℃ to 80℃ (continuous operation)
- Surface treatment: Anodized aluminum body with chromate plating
- Pressure drop: ≤0.02 MPa at 0.5 MPa supply
- Vibration resistance: 10–55Hz with 1.5mm amplitude
- Protection rating: IP67 (when valves fully installed)
The ESV301M serves as the foundational component for building compact valve manifolds, featuring precision-machined air passages that minimize pressure loss. Its dual-row O-ring sealing system ensures leak-free connections even under high vibration conditions. The modular design allows cascading multiple units for complex pneumatic circuits while maintaining a 21mm standardized spacing between valve positions.
- Multi-axis robotic end effector control systems
- Plastic injection molding machine clamp units
- Automated assembly line fixture sequencing
- Textile machinery pneumatic logic clusters
- Semiconductor wafer handling vacuum/pressure systems
Installation protocol:
Apply thread sealant only on male ports (PT), keep manifold surface temperature below 60℃ during operation.
Use torque-controlled tightening (1.5–2.0 N·m for valve mounting screws). Maintain 15mm clearance below manifold
for tubing access. Pre-flush with dry air before commissioning.
| Property | Property Value |
|---|---|
| sku | ESV301M |
| Port Size | PT3/8 |
