Airtac ESV-M Base ESV302MGW
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base ESV302MGW Technical Specifications
- Model: ESV302MGW (M Series Universal Base)
- Compatible Valves: ESV-M5/M7/M10/M15/M20 series solenoid valves
- Port Configuration: 3/2-way, 5/2-way, 5/3-way selectable via manifold
- Port Size: PT1/4 (G1/8 optional)
- Max Operating Pressure: 1.0 MPa
- Body Material: Anodized aluminum alloy (anti-corrosion treatment)
- Seal Material: NBR/FKM (optional fluorocarbon rubber)
- Temperature Range: -20℃ to 80℃ (with FKM seals up to 150℃)
- Mounting Type: ISO 15407-1 compliant sub-base with M4 mounting holes
- Electrical Connection: 2.5mm² screw terminals (gold-plated contacts)
- Weight: 280g ±5%
- Dimensions: 62mm(L) × 44mm(W) × 34mm(H)
- Port Pitch: 18mm (standard modular spacing)
- Surface Finish: Black oxidation with laser-etched port markings
Modular valve base engineered for multi-valve manifold systems, featuring tool-free valve locking mechanism and integrated silencer options. The staggered port design prevents tool interference during plumbing. Includes built-in pilot exhaust ports with dust-resistant mesh filters. Compatible with vacuum applications when paired with ESV-MV series valves.
- Multi-station pneumatic control panels
- Automated assembly line sequencing systems
- Packaging machinery with clustered valve operations
- Semiconductor handling equipment requiring vibration resistance
- Mobile hydraulic hybrid systems (construction machinery)
Installation Protocol:
Apply 3-5Nm torque during mounting. Use thread sealant only on male threads,
never on base unit. For multi-valve stacks, install support brackets every 6 units.
Maintain 50mm clearance below base for manifold piping access.
- Dual-color status indicators (mechanical flags for visual confirmation)
- EMC-shielded cable routing channels
- Reverse polarity protection for electrical connections
- IP67 rating when used with optional protective cover (ACC-ESV3)
| Property | Property Value |
|---|---|
| sku | ESV302MGW |
| Port Size | PT3/8 |
