Airtac ESV-M Base ESV302MGWR
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base Unit ESV302MGWR Technical Specifications
- Model: ESV302MGWR
- Series: ESV-M Modular Valve Base
- Port size: PT1/4 (G1/4 equivalent)
- Number of positions: 3-position (3-way)
- Port configuration: 5-port (P, A, B, EA, EB)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Voltage compatibility: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Manual override: Built-in emergency manual switch
- Seal material: NBR (Nitrile) with reinforced glass fiber body
- Temperature tolerance: -20℃ to 80℃ (operating fluid)
- Flow capacity: Cv=1.2 (at 0.5 MPa)
- Mounting style: Panel mount with G-thread ports
- Weight: 280g ±5% (without solenoid)
- Dimensions: 50mm(W) × 40mm(H) × 25mm(D)
- Protection class: IP67 (when properly installed)
- Response time: ≤30ms (at rated voltage)
Modular pneumatic base unit designed for multi-functional valve combinations, featuring dual exhaust ports (EA/EB) for precise flow control. The reinforced composite body withstands high-cycle operations with vibration-resistant thread locking. Compatible with all ESV-M series solenoid heads and accessories.
- Multi-station pneumatic clamping systems
- Automated assembly line sequencing
- Plastic injection molding machine controls
- Textile machinery tension regulation
- Semiconductor handling equipment
Installation requirements:
Use M4 mounting screws with 0.6-0.8Nm torque. Maintain horizontal alignment
when stacking multiple units. Apply thread sealant (LOCTITE 542) on port
connections. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 quality.
| Property | Property Value |
|---|---|
| sku | ESV302MGWR |
| Port Size | PT3/8 |
