Airtac ESV-M Base ESV401MB
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base Unit ESV401MB Technical Specifications
- Model: ESV401MB
- Type: Modular valve manifold base for ESV-M series
- Port size: PT1/4 (G1/4 optional)
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Anodized (black)
- Mounting hole spacing: 40mm (ISO 15407-1 compliant)
- Max operating pressure: 1.0 MPa
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Compatible valves: ESV-M20, ESV-M25 series
- Port thread depth: 12mm (full thread engagement)
- Weight: 220g ±5g
- Dimensions: 40mm(W) × 40mm(H) × 25mm(D)
- Seal material: NBR (standard), optional FKM
- Pressure drop: ≤0.03 MPa at 500L/min
- Mounting torque: 1.5-2.0 N·m (aluminum screws)
Precision-machined manifold base featuring multi-stage sealing design with redundant O-ring protection. The T-slot mounting system enables tool-less valve stacking and supports up to 3-valve combinations. Integrated air passageways minimize pressure loss through optimized 2.5mm diameter flow channels.
- Modular pneumatic control stations in automotive assembly lines
- Multi-axis actuator control systems
- Compact valve clusters for semiconductor handling robots
- Mobile equipment requiring vibration-resistant manifolds
- Centralized control panels for packaging machinery
Installation protocol:
Apply thread sealant only on male ports (not required for flat-seat connections).
Use torque wrench for even pressure distribution across manifold.
Perform 3-cycle pressure test (0-1.0 MPa) before full operation.
| Property | Property Value |
|---|---|
| sku | ESV401MB |
| Port Size | PT 1/2 |
