Airtac ESV Solenoid Valve ESV210A
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210A Solenoid Valve Technical Details
- Model: ESV210A
- Type: 5/2-way double solenoid (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (50/60Hz)
- Weight: 350g ±5% (with connectors)
- Dimensions: 82mm(L) × 34mm(W) × 50mm(H)
- Seal material: FKM (Viton) / NBR selectable
- Temperature range: -10℃ to 80℃ (NBR) / -10℃ to 150℃ (FKM)
- Power consumption: 2.2W (DC) / 4.5VA (AC)
- Response time: ≤15ms (exhaust to actuation)
- Flow capacity: 750L/min (ANR)
- Protection rating: IP67 (coil)/ IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow bistable solenoid valve with dual-coil latching design for energy-efficient operation. Features triple-sealed piston structure for leak-free performance in vacuum or pressure applications. Optimized for high-cycle automation systems requiring position memory function without continuous power supply. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Pneumatic cylinder position control in assembly lines
- Plastic injection molding machine clamp systems
- Food processing equipment with CIP washdown requirements
- Automotive brake testing rigs
- Battery manufacturing vacuum handling systems
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
Maintain minimum 20mm clearance below valve for exhaust port maintenance.
Use shock absorbers in high-cycle (>5Hz) applications.
Critical note:
When using FKM seals, avoid phosphate ester-based lubricants.
Always install downstream 5μm filter with auto-drain for compressed air systems.
| Property | Property Value |
|---|---|
| sku | ESV210A |
| Standard Voltage | AC220V |
