Airtac ESV Solenoid Valve ESV210B
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210B Solenoid Valve Technical Details
- Model: ESV210B (ISO 15407-1 compliant)
- Valve type: 5/2-way monostable, single solenoid
- Port configuration: G1/8 (NPT1/8 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Flow capacity: 750 l/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Weight: 280g ±5% (with coil)
- Dimensions: 58mm(L) × 40mm(W) × 74mm(H)
- Seal materials: HNBR (main seals), FKM (optional for chemical resistance)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A (standard), lead wire option
High-flow directional control valve with aluminum alloy body and hardened stainless steel spool. Features manual override button for system debugging and emergency operation. Designed for high-cycle applications (≥50 million operations) with built-in surge suppression for coil protection. Requires 5μm filtered compressed air with max 5% relative humidity.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and spindle brakes
- Textile machinery cylinder control
- Automotive tire assembly equipment
Maintenance advice:
Lubricate spool monthly with ISO VG32 pneumatic oil. Install upstream
40μm filter and use shielded cable for electrical connections in high EMI environments.
| Property | Property Value |
|---|---|
| sku | ESV210B |
| Standard Voltage | DC24V |
