Airtac ESV Solenoid Valve ESV210BI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210BI Solenoid Valve Technical Details
- Model: ESV210BI
- Type: 5/2-way single solenoid, spring return (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including coil)
- Dimensions: 56mm(L) × 40mm(W) × 75mm(H)
- Flow coefficient (Cv): 1.8
- Seal material: NBR/FKM (optional Viton for high temp)
- Temperature range: -5℃ to 80℃ (extended to 120℃ with FKM seals)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (coil protection)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with dual-position memory function, featuring brass body construction with hard anodized aluminum piston. Designed for rapid cycling applications requiring precise air flow reversal. Integrated LED manual override and surge suppression circuitry. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Pneumatic cylinder control in automated assembly lines
- Textile machinery thread tension systems
- Plastic injection molding machine actuators
- Automotive testing equipment
- Food processing pneumatic circuits (food-grade version available)
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction.
Use flexible tubing to prevent vibration transfer.
Minimum 15mm clearance required above coil for heat dissipation.
Lubricate every 5 million cycles under continuous operation.
| Property | Property Value |
|---|---|
| sku | ESV210BI |
| Standard Voltage | DC24V |
