Airtac ESV Solenoid Valve ESV210BW
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210BW Solenoid Valve Technical Specifications
- Model: ESV210BW (Enhanced Silent Version)
- Type: 5/2-way double solenoid, double pilot operated
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 1.2W (DC), 2.5VA (AC)
- Response time: ≤15ms (exhaust to full flow)
- Flow rate: 750 NL/min (ANR, at 0.5MPa)
- Seal materials: NBR standard (FKM optional)
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Medium temperature: 0℃ to 60℃
- Protection class: IP67 (coil), IP40 (valve body)
- Weight: 450g ±5% (including coil)
- Dimensions: 58mm(W) × 50mm(H) × 120mm(L)
- Mounting: ISO 5599-1 standard interface
High-flow proportional solenoid valve with noise reduction design (≤55dB), featuring brass body with electroless nickel plating for corrosion resistance. The dual coil structure enables latching control capability. Includes manual override and position indicator. Requires 5μm filtered compressed air with oil mist (ISO 8573-1 Class 3.4.2).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and pallet systems
- Semiconductor wafer handling robotics
- Beverage canning line pneumatic controls
Installation guidelines:
Mount in vibration-free environment using ISO 6432 brackets. Maintain minimum
20mm clearance below valve for exhaust flow. Lubricate using ISO VG32 turbine oil
if operating below 0℃. Perform monthly manual cycling during standby periods.
| Property | Property Value |
|---|---|
| sku | ESV210BW |
| Standard Voltage | DC24V |
