Airtac ESV Solenoid Valve ESV210CI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210CI 5/2-Way Solenoid Valve Technical Specifications
- Model: ESV210CI
- Valve type: 5/2-way, double solenoid (dual coil)
- Operation type: Double pilot operated
- Port size: PT1/4 (G1/4 optional)
- Effective area: 17mm² (pilot orifice)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Proof pressure: 1.2 MPa max
- Voltage options: DC12V(±10%), DC24V(±10%), AC110V(±10% 50/60Hz), AC220V(±10% 50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (exhaust to output)
- Flow coefficient (Cv): 1.8
- Seal material: Heat-resistant NBR (-5℃ to 80℃) / Optional FKM (-10℃ to 150℃)
- Body material: Aluminum alloy with hard anodizing
- Protection class: IP67 (coil), IP40 (valve body)
- Weight: 320g ±5% (including coil)
- Dimensions: 55mm(L) × 40mm(W) × 80mm(H)
- Port thread depth: 12mm
- Manual override: Optional paddle-type
High-speed 5/2 pneumatic solenoid valve featuring dual-coil latching design for bistable control. The ESV210CI incorporates a pilot piston structure with wear-resistant guide rings, achieving over 50 million cycles MTBF. Optimized flow path design reduces pressure loss by 15% compared to previous generation models. Compatible with vacuum applications when paired with vacuum generators.
- Automated assembly line clamping/unclamping systems
- Plastic injection molding machine ejectors
- Textile machinery cylinder control
- Semiconductor wafer handling robots
- Bottle blowing machine air circuit switching
Installation guidelines:
Mount in vibration-free environment with ≤0.5mm alignment tolerance.
Maintain vertical orientation (±15° max deviation). Use ISO 8573-1:2010
Class 4 compressed air (max oil content 1mg/m³). Install downstream
40μm filter with auto-drain. Allow 12mm clearance for manual override operation.
| Property | Property Value |
|---|---|
| sku | ESV210CI |
| Standard Voltage | AC 110V |
