Airtac ESV Solenoid Valve ESV210E
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210E 5/2-Way Solenoid Valve Specifications
- Model: ESV210E
- Type: 5/2-way double solenoid (double pilot)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Weight: 220g ±5g
- Dimensions: 55mm(L) × 35mm(W) × 70mm(H)
- Seal material: Heat-resistant NBR (nitrile rubber)
- Temperature range: -5℃ to 80℃ (with 5℃ safety margin)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dust-tight, waterproof immersion up to 1m)
- Flow capacity: CV 0.5 (Kv 0.43)
- Port thread depth: 10mm (parallel thread)
- Lubrication: Non-required (pre-lubricated for 1 million cycles)
High-flow bistable solenoid valve with dual-coil latching design, engineered for energy-efficient operation in harsh environments. Features brass body with hard anodized aluminum solenoid housing, providing EMI/RFI shielding. Requires ISO 8573-1 class 3 compressed air (max 50mg/m³ oil content).
- Automated assembly line actuators
- Offset printing press cylinder control
- Food packaging machine clamp sequencing
- Automotive test bench brake simulation
- Plastic injection molding ejectors
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance around coils for heat dissipation. Use surge protector
for DC models in high-inductance circuits.
| Property | Property Value |
|---|---|
| sku | ESV210E |
| Standard Voltage | AC24V |
