Airtac ESV Solenoid Valve ESV210F
$67.43
Regular price
$74.93
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ESV210F
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Sleek appearance with compact design;
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
Installation guidelines:
Mount in any orientation with ≥30mm clearance for coil heat dissipation.
Use shock-absorbing brackets in high-vibration environments.
Lubricate seals with ISO VG32 pneumatic oil annually.
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210F 5/2-Way Solenoid Valve Technical Details
- Model: ESV210F
- Valve type: 5/2-way single solenoid (spring return)
- Port configuration: PT1/4 (G1/4 optional)
- Operation mode: Indirect pilot-operated
- Pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC12V/24V ±10%, AC110V/220V ±10% (50/60Hz)
- Flow capacity: 650 l/min (Cv=1.2)
- Response time: ≤25ms (actuation), ≤15ms (release)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Body material: Anodized aluminum alloy
- Protection class: IP67 (dust/water resistant)
- Weight: 320g ±5%
- Dimensions: 55mm(L) × 35mm(W) × 75mm(H)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional solenoid valve with dual-position control, featuring anti-vibration design for industrial environments. Equipped with manual override and LED status indicator. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content).
Ideal for:
- Pneumatic cylinder sequence control systems
- Textile machinery air circuit switching
- Automated assembly line actuators
- Semiconductor handling equipment
- Beverage filling machine valve clusters
Installation guidelines:
Mount in any orientation with ≥30mm clearance for coil heat dissipation.
Use shock-absorbing brackets in high-vibration environments.
Lubricate seals with ISO VG32 pneumatic oil annually.
| Property | Property Value |
|---|---|
| sku | ESV210F |
| Standard Voltage | DC12V |
