Airtac ESV Solenoid Valve ESV220BI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220BI Solenoid Valve Specifications
- Model: ESV220BI
- Type: 5/2-way single solenoid (pilot-operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 410g ±5g (including coil)
- Dimensions: 70mm(L) × 40mm(W) × 82mm(H)
- Flow rate: 1,200 l/min (ANR) at 0.5 MPa
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.2W (DC) / 4.5VA (AC)
- Response time: ≤15ms (exhaust to full actuation)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (PT1/4)
High-flow directional control valve with rapid switching capability, featuring brass main body and reinforced polymer components for chemical resistance. Designed for heavy-duty pneumatic circuits requiring precise cylinder control. Includes manual override button and LED operation indicator. Requires ISO 8573-1 Class 3 compressed air (max 50mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Material handling robotics (end-effector controls)
- Food processing pneumatic circuits (dry environments)
- Automotive tire assembly equipment
Installation note:
Mount with vibration-damping brackets in high-cycle applications.
Maintain 20mm minimum clearance below valve for condensate drainage.
Use anti-seize compound on port threads for aluminum manifolds.
| Property | Property Value |
|---|---|
| sku | ESV220BI |
| Standard Voltage | DC24V |
