Airtac ESV Solenoid Valve ESV220BW
$90.69
Regular price
$98.19
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ESV220BW
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Sleek appearance with compact design;
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
Installation guidelines:
Maintain ≤3° deviation from vertical mounting position. Use vibration-damping mounts in high-shock environments.
For optimal performance, install a downstream speed controller (ASC-04 type recommended) and maintain ambient
humidity below 85% RH. Allow 15mm clearance around valve for heat dissipation.
Critical note:
Do NOT use silicone-based lubricants. Cycle frequency must not exceed 5Hz continuous operation.
Always install an emergency pressure relief valve when used in accumulator circuits.
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220BW Solenoid Valve Technical Details
- Model: ESV220BW
- Type: 5-port 2-position (5/2-way) double solenoid operated
- Port configuration: 1/4" BSPP (G1/4) threaded ports
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤20ms (energize), ≤30ms (de-energize)
- Flow capacity: Cv=0.45 (at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Ambient temperature: -5℃ to 60℃ (with no freezing)
- Fluid temperature: 0℃ to 60℃
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 350g ±5% (excluding accessories)
- Dimensions: 80mm(L) × 45mm(W) × 55mm(H)
- Manual override: Built-in push-button manual operation
- Electrical connection: DIN43650 Form A connector
High-flow proportional solenoid valve with dual-coil latching design for energy-saving operation. Features corrosion-resistant aluminum alloy body with anodized surface treatment and zero-pressure differential start capability. Requires 5μm filtered compressed air with lubrication (ISO 8573-1 Class 3.4.2).
Industrial Applications:
- Automated assembly line clamping/unclamping systems
- Plastic injection molding machine ejectors
- CNC tool changers and spindle brakes
- Textile machinery tension control
- Automotive tire inflation systems
- Bottle capping/packaging equipment
Installation guidelines:
Maintain ≤3° deviation from vertical mounting position. Use vibration-damping mounts in high-shock environments.
For optimal performance, install a downstream speed controller (ASC-04 type recommended) and maintain ambient
humidity below 85% RH. Allow 15mm clearance around valve for heat dissipation.
Critical note:
Do NOT use silicone-based lubricants. Cycle frequency must not exceed 5Hz continuous operation.
Always install an emergency pressure relief valve when used in accumulator circuits.
| Property | Property Value |
|---|---|
| sku | ESV220BW |
| Standard Voltage | DC24V |
