Airtac ESV Solenoid Valve ESV220E
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220E Solenoid Valve Technical Specifications
- Model: ESV220E Series
- Valve type: 5/2-way direct acting (double solenoid)
- Port configuration: G1/4" (ISO standard)
- Operating pressure range: 0.1-1.0 MPa
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Weight: 0.68 kg (including coil)
- Dimensions: 55mm(H) × 54mm(W) × 108mm(L)
- Seal materials: HNBR (Hydrogenated Nitrile) with FKM backup rings
- Temperature resistance: -10℃ to 80℃ (with silicone seals optional for -20℃)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Maximum flow rate: 1200 NL/min (ANR)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
The ESV220E features a dual-coil latching design for energy-efficient operation, maintaining position without continuous power. Its all-metal piston construction ensures 1 million+ cycle durability. Optimized flow paths reduce pressure drop by 18% compared to previous models. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Robotic arm end-effector control systems
- Plastic injection molding machine clamp mechanisms
- Automated assembly line positioning cylinders
- Textile machinery tension control systems
- Semiconductor wafer handling equipment
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 50mm clearance above valve for heat dissipation.
Use Loctite 542 on port threads - torque to 15N·m maximum.
Perform monthly air filter inspection in high-cycling applications.
| Property | Property Value |
|---|---|
| sku | ESV220E |
| Standard Voltage | AC24V |
