Airtac ESV Solenoid Valve ESV220EI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220EI 5/2-Way Solenoid Valve Technical Details
- Full model designation: ESV220EI
- Valve type: 5/2-way single solenoid (pilot-operated)
- Port thread: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15-0.8 MPa (21.7-116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 0.52 at 6 bar
- Response time: ≤15ms (at rated voltage)
- Body material: Brass with nickel plating
- Seal compound: Heat-resistant NBR (Nitrile rubber)
- Ambient temperature: -5℃ to 80℃ (23°F to 176°F)
- Weight: 450g ±5% (excluding connectors)
- Dimensions: 80mm(L) × 50mm(W) × 75mm(H)
- Protection class: IP65 (dust-tight & water jet resistant)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Manual override: Optional push-button type
The ESV220EI features a robust 5/2-way configuration with dual-pressure control capability, engineered for complex pneumatic circuits requiring precise directional control. Its hardened brass construction withstands vibration-heavy environments, while the low-friction spool design ensures consistent performance through 50 million cycles. Requires 5-40μm filtered compressed air with oil mist lubrication recommended.
- Robotic arm gripper actuation systems
- Plastic injection molding machine ejectors
- Automotive assembly line clamping mechanisms
- Food processing pneumatic cylinder control
- Printing press air logic circuits
Installation protocol:
Mount in horizontal orientation to prevent debris accumulation.
Use shock-absorbing brackets in high-vibration applications.
Maintain 15mm minimum clearance for coil heat dissipation.
Always install downstream moisture separator.
| Property | Property Value |
|---|---|
| sku | ESV220EI |
| Standard Voltage | AC24V |
