Airtac ESV Solenoid Valve ESV230CA
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV230CA Solenoid Valve Technical Specifications
- Model: ESV230CA
- Type: 5/2-way single solenoid control (spring return)
- Port size: PT1/4 (G1/8 adapter available)
- Operating pressure range: 0.15–1.0 MPa
- Maximum flow rate: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (with coil)
- Dimensions: 56mm(W) × 54mm(H) × 105mm(L)
- Body material: Die-cast aluminum alloy (anodized finish)
- Seal compounds: HNBR/Nitrile (standard), optional FKM/Viton
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (straight thread with O-ring seal)
High-flow directional control valve featuring integrated silencer and manual override. The dual-chamber design ensures stable switching under variable pressure conditions. Optimized for high cycle rates (up to 5Hz) with copper-free aluminum construction meeting ISO 8573-1 air quality standards. Includes surge suppression circuit for coil protection.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery clamp controls
- Plastic injection molding machine ejectors
- Automotive tire assembly systems
- Food processing pneumatic actuators (with optional FDA seals)
Installation guidelines:
Mount in vibration-free location using M5 mounting brackets (included).
Maintain minimum 15mm clearance above valve for heat dissipation.
Use 5-10μm filtration with automatic drain. Lubricated air requires
oil mist supplement (ISO VG32 recommended).
- Mechanical durability: 50 million cycles
- Coil insulation class: F (155℃)
- Recommended maintenance: Inspect seals every 2 million cycles
| Property | Property Value |
|---|---|
| sku | ESV230CA |
| Standard Voltage | AC 110V |
