Airtac ESV Solenoid Valve ESV230CC
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV230CC Solenoid Valve Technical Specifications
- Model: ESV230CC
- Type: 5/3-way double solenoid (closed center)
- Port size: G1/4 (ISO228/1 standard)
- Operating pressure: 0.1–1.0 MPa
- Voltage variants: DC12V(±10%), DC24V(±10%), AC110V(50/60Hz), AC220V(50/60Hz)
- Flow capacity: 1200 L/min (ANR)
- Weight: 350g ±5% (excluding connector)
- Dimensions: 80mm(L) × 45mm(W) × 70mm(H)
- Body material: Die-cast aluminum alloy with epoxy coating
- Seal material: Heat-resistant FKM fluorocarbon rubber
- Temperature range: -10℃ to 90℃ (non-freezing)
- Response time: ≤20ms (at rated voltage)
- Power consumption: 2.5W (DC), 5VA (AC)
- Protection class: IP67 (dustproof/water immersion resistant)
- Mounting type: ISO 4400 standard subplate
- Port thread depth: 12mm (full thread engagement recommended)
High-flow proportional control valve with center-block function, featuring anti-vibration terminals and manual override capability. Optimized for precision position control in hydraulic/pneumatic hybrid systems. Requires filtered air (≤50μm particles) with lubricator (ISO VG32 oil mist recommended).
- Automated assembly line clamping systems
- Plastic injection molding machine hydraulics
- Food processing pneumatic actuators (NSF compliant)
- Battery production vacuum handling
- Textile machinery tension control
Installation protocol:
Use copper-free anti-seize compound on threads. Maintain ambient temperature below 80℃.
For vertical mounting, position coil terminals upward to prevent condensation ingress.
Critical note:
Not compatible with phosphate ester fluids. Minimum 2-second interval required between
consecutive energization cycles for thermal protection.
| Property | Property Value |
|---|---|
| sku | ESV230CC |
| Standard Voltage | AC 110V |
