Airtac ESV Solenoid Valve ESV230CCI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV230CCI Solenoid Valve Technical Specifications
- Model: ESV230CCI
- Valve type: 5/2-way single solenoid spring return
- Port configuration: 2-position, 5-port
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 2.3 (at 7 bar)
- Seal material: Heat-resistant NBR (Nitrile), optional Viton available
- Temperature range: -10℃ to 80℃ (NBR standard), -10℃ to 150℃ with Viton seals
- Response time: ≤25ms (energized), ≤35ms (de-energized)
- Protection class: IP67 (dust-tight, protected against temporary immersion)
- Weight: 330g ±5g (excluding connectors)
- Dimensions: 78mm(L) × 45mm(W) × 68mm(H)
- Accessories: Optional manual override, LED indicator, DIN connector
High-flow directional control valve engineered for industrial automation systems requiring rapid cycling. Features aluminum alloy body with hard anodized coating for corrosion resistance. The pilot-operated design ensures reliable switching under vibration conditions. Compatible with ISO 15407-1 standards, requires 5μm filtered compressed air with lubrication (ISO 8573-1 class 4).
- Pneumatic cylinder sequencing in automotive assembly lines
- Actuator control for packaging machinery (cartoners, fillers)
- Plastic injection molding machine clamp systems
- Textile machinery thread control mechanisms
- Paper processing equipment pneumatic circuits
Installation guidelines:
Mount in vibration-damped position using M4 mounting screws. Maintain minimum
15mm clearance around exhaust ports for heat dissipation. Use anti-vibration
washers in high-cycle applications (>5Hz). Lubricate every 5 million cycles
using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ESV230CCI |
| Standard Voltage | AC 110V |
