Description
Product Category: Floating Joint Assemblies
Brand: AirTAC
Series: F-M-F Flange-Type Rod End Couplings
Professional Description:
AirTAC F-M-F Series Floating Joints are precision-engineered misalignment compensators designed for pneumatic and automation systems. This complete assembly features dual-flange connectivity with male/female threaded interfaces (F-M-F configuration), enabling angular deflection compensation up to ±5° and parallel offset absorption. Constructed with hardened steel swivel joints and corrosion-resistant mounting hardware, these industrial-grade couplings ensure reliable torque transmission while mitigating lateral stresses in cylinder-rod and mechanical linkage applications. The pre-lubricated bearing surfaces provide smooth articulation for high-cycle operations, making them ideal for robotic end-effector connections and precision alignment-critical installations.
Installation protocol:
Apply medium-strength thread locker (Loctite 243 recommended) on male threads.
Torque to 45-50Nm using crowfoot wrench. Perform alignment check after 500 cycles
and re-torque if necessary. Lubricate quarterly with ISO VG32 hydraulic oil.
AirTAC F-M-F Floating Joint Kit F-M16X150F Technical Specifications
- Model: F-M16X150F
- Type: Floating joint complete assembly (male/female threaded)
- Thread specification: M16×2.0 (external) / M16×1.5 (internal)
- Rod diameter: Ø16mm ±0.015mm
- Effective stroke: ±2.5° angular compensation
- Max. axial displacement: ±1.2mm
- Material: Steel body with PTFE-impregnated bronze bushings
- Static load capacity: 1,250N radial / 850N axial
- Dynamic load rating: 320N at 0.3m/s
- Temperature range: -30℃ to +120℃ (dry operation)
- Surface treatment: Black oxide coating (Fe/Of)
- Weight: 0.68kg ±3%
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H)
- Protection class: IP54 (standard sealing)
- Torque resistance: ≤0.5Nm under full load
Precision-engineered floating joint assembly with self-lubricating bushings, designed to compensate for axial/angular misalignment in linear motion systems. Features dual O-ring seals (NBR material) and hardened steel construction for extended service life in high-cycle applications.
Typical Applications:
- Pneumatic cylinder rod-end compensation in pick-and-place systems
- Vibration isolation for servo motor-driven actuators
- Misalignment correction in conveyor belt tensioning mechanisms
- Shock absorption for robotic welding gun installations
- Precision alignment in semiconductor handling equipment
Installation protocol:
Apply medium-strength thread locker (Loctite 243 recommended) on male threads.
Torque to 45-50Nm using crowfoot wrench. Perform alignment check after 500 cycles
and re-torque if necessary. Lubricate quarterly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | F-M16X150F |
| Thread Pitch | 1.5mm |
| Thread Specification | 16mm |
