Airtac F-M-F Floating Joint Assembly F-M18X150F
AirTAC F-M-F Floating Joint Assembly F-M18X150F Technical Details
- Full model designation: F-M18X150F (Male-Female floating joint kit)
- Thread specification: M18×1.5 precision metric thread
- Effective stroke: ±2° angular compensation / ±0.5mm axial float
- Max load capacity: 1,200N radial / 800N axial
- Body material: Anodized aluminum alloy (AL6061-T6)
- Seal type: Dual NBR O-rings with PTFE backup washers
- Surface treatment: Hard oxidation 15-25μm (black)
- Temperature range: -20℃ to +120℃ (continuous operation)
- Weight: 0.23kg (complete assembly)
- Dimensions:
- Total length: 150±0.3mm
- Flange diameter: 32mm
- Mounting hole spacing: 40mm (dual M5 threaded holes)
- Hex wrench size: 24mm (for installation)
Precision-machined floating joint designed for pneumatic systems requiring misalignment compensation. Features triple chrome-plated steel ball bearings within the floating mechanism for smooth articulation. The nickel-plated locknut ensures vibration resistance up to 15Hz frequency. Includes pre-assembled stainless steel washers and anti-decoupling safety clips.
- Industrial robot end-effector tool changers
- High-speed packaging machine rotary joints
- CNC machine tool coolant line connections
- Automated welding torch alignment systems
- Semiconductor wafer handling robotics
Installation protocol:
Apply thread sealant (LOCTITE 577 recommended) on male threads before assembly.
Tighten to 25-30N·m torque using calibrated wrench. Perform axial alignment check
using 0.02mm feeler gauge during installation. Replace O-rings every 500,000 cycles
under continuous operation.
| Property | Property Value |
|---|---|
| sku | F-M18X150F |
| Thread Pitch | 1.5mm |
| Thread Specification | 18mm |
