Airtac F-M-F Floating Joint Assembly F-M36X200F
AirTAC F-M-F Floating Joint Assembly F-M36X200F Technical Details
- Model: F-M36X200F
- Type: Double-acting floating joint with pre-assembled rod ends
- Thread specification: M36×1.5 (male thread both ends)
- Stroke length: 200mm (±10mm compensation range)
- Material:
- Body: Hard-anodized aluminum alloy
- Ball seat: Wear-resistant brass with PTFE coating
- Seals: HNBR rubber (standard), optional Fluorocarbon
- Max working pressure: 0.7 MPa (7 bar)
- Temperature range: -20℃ to +80℃ (standard seals)
- Torque capacity: ≤15 N·m (dynamic), ≤35 N·m (static)
- Mounting: Dual flange support with M8×1.25 mounting holes (4x)
- Weight: 1.2 kg ±5% (including rod ends)
- Dimensions:
- Total length: 280mm (extended)
- Flange diameter: 80mm
- Body height: 50mm (from mounting surface)
Precision-machined floating joint assembly designed for heavy-duty misalignment compensation in linear motion systems. Features anti-backlash ball-and-socket design with 3° angular compensation and ±2mm axial play. Includes pre-lubricated maintenance-free bearings and corrosion-resistant surface treatment.
- Industrial robot wrist joint compensation
- CNC machine tool automatic pallet changers
- Packaging line conveyor height adjustment mechanisms
- Hydraulic cylinder end connections in off-road vehicles
- Semiconductor wafer handling robotic arms
Installation guidelines:
Always install with minimum 15mm free space around rotating parts.
Apply lithium-based grease to thread interfaces during assembly.
Perform torque check every 500 operating hours (recommended 25-30 N·m).
| Property | Property Value |
|---|---|
| sku | F-M36X200F |
| Thread Pitch | <2.0mm> |
| Thread Specification | <36mm> |
