Airtac F-M-F Floating Joint Assembly F-M3X050F
AirTAC F-M-F Floating Joint Kit F-M3X050F Technical Details
- Full model designation: F-M3X050F (Complete assembly kit)
- Thread specification: M3×0.5 male thread both ends
- Float compensation: ±0.5mm radial / ±2° angular
- Max axial load: 98N (10kgf)
- Max lateral load: 49N (5kgf)
- Body material: Stainless steel SUS303
- Ball joint material: Case-hardened carbon steel (HRC 50-55)
- Seal type: Double NBR O-rings (FDA compliant)
- Operating temperature: -20℃ to 80℃ (continuous) / 120℃ peak
- Surface treatment: Electroless nickel plating (5-8μm)
- Weight: 28g ±1g (including all hardware)
- Dimensions: 50mm(L) × 16mm(W) × 16mm(H)
- Torque rating: 0.49N·m max during installation
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision floating joint assembly designed for micron-level misalignment compensation in compact pneumatic systems. Features zero-backlash ball joint mechanism with dual sealing for leak-free operation in vacuum applications. Includes pre-installed lock nuts and alignment washers for tool-free installation.
- High-speed pick-and-place robot end effectors
- Semiconductor wafer handling vacuum arms
- Medical device pneumatic biopsy tools
- 3D printer extruder head stabilization systems
- Precision optical lens positioning stages
Mounting protocol:
Apply 2-3 drops of ISO VG32 pneumatic oil to ball socket before final assembly.
Torque sequence: Tighten body nut first to 0.4N·m, then locknut to 0.2N·m.
Avoid PTFE tape – use liquid thread sealant instead.
| Property | Property Value |
|---|---|
| sku | F-M3X050F |
| Thread Pitch | <0.5 mm> |
| Thread Specification | <3mm> |
