Airtac F-M-F Floating Joint Assembly F-M5X080F
AirTAC F-M-F Floating Joint Assembly F-M5X080F Technical Details
- Model Code: F-M5X080F
- Type: Dual-ball floating joint with pre-assembled bracket
- Thread Specification: M5×0.8 male threads (both ends)
- Material Composition:
- Body: Anodized aluminum alloy (AL6061-T6)
- Ball Heads: Case-hardened stainless steel (SUS440C)
- Seals: High-wear NBR+PU hybrid seals
- Angular Compensation: ±2° axial misalignment / ±1.5° radial deflection
- Max Working Pressure: 1.0 MPa (10 bar)
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Torque Resistance: ≤0.15 N·m under max pressure
- Weight: 68g ±2g (including mounting hardware)
- Dimensions:
- Total Length: 80mm (center-to-center)
- Body Diameter: Φ16mm
- Bracket Size: 25mm(W) × 32mm(H) × 8mm(T)
- Vibration Resistance: 5-2000Hz, 15G acceleration (IEC 60068-2-6)
Precision-aligned floating joint assembly designed for pneumatic systems requiring vibration dampening and misalignment compensation. Features triple-layer sealing architecture with dust-resistant wiper rings. Includes zinc-plated steel mounting bracket with M4 fasteners for 8mm panel thickness.
- Robotic end-effector tool changers (EOAT)
- High-cycle packaging machine rotary unions
- CNC tool magazine pneumatic couplings
- Semiconductor wafer handling arms
- Food processing conveyor alignment compensators
Installation Protocol:
Apply 2-3 drops of ISO VG32 pneumatic oil to ball heads before initial use.
Torque limit: 1.2-1.5 N·m during installation. Avoid side-load exceeding 50N.
Note: Replace entire assembly if radial play exceeds 0.3mm
| Property | Property Value |
|---|---|
| sku | F-M5X080F |
| Thread Pitch | <0.8 mm> |
| Thread Specification | <5mm> |
